2-12 strips PP strapping band production line pp strapping band making machine automatic PP strapping band
Product Description of pp strapping band making machine:
pp strapping band making machine
pp strapping band making machine can be customized according to customer requirements and can extrude 2-12 PP straps at the same time.
WORKING PROCESS
Raw material preparation----Add PP granules into the extruder hopper.
Extrusion molding----PP granules are melted in the extruder and extruded through the mold.
Cooling and shaping----The extruded strapping tape enters the cooling water tank for cooling and shaping.
Traction and stretching---- The traction machine pulls the strapping tape, and the stretching machine performs stretching treatment.
Embossed treatment---- The embossing machine embosses the surface of the strapping tape.
Shaping oven---- Heat and shape the PP tape again to achieve consistent specifications.
Reeling and packaging----The reeling machine winds the strapping tape into a roll and puts it into storage after packaging.
Raw materials------
100% PP polypropylene new material or recycled material
EXTRUSION PARAMETERS TABLE
|
Model
|
PP-2
|
PP-4
|
PP-6
|
PP-8
|
PP-10
|
PP-12
|
|
Raw material
|
PP polypropylene new material/recycled material
|
|
Number of tapes
|
2
|
4
|
6
|
8
|
10
|
12
|
|
Width(mm)
|
5-19
|
5-19
|
5-19
|
5-19
|
5-19
|
5-19
|
|
Thickness(mm)
|
0.4-1.2
|
0.4-1.2
|
0.4-1.2
|
0.4-1.2
|
0.4-1.2
|
0.4-1.2
|
|
Line speed(m/min)
|
≧260-300
|
|
PLC control system
|
PLC
|
PLC
|
PLC
|
PLC
|
PLC
|
PLC
|
|
Screw Model
|
90
|
110
|
125
|
135
|
135
|
135
|
|
Reducer model
|
200
|
220
|
250
|
280
|
280
|
280
|
|
Winding machine
|
Automatic winding machine /Semi-automatic winding machine
|
|
Screen Changer
|
Automatic/Manua
|
|
Production capacity 24H
|
2.5-3T
|
6-7T
|
8-9T
|
10-11T
|
12-13T
|
13--14T
|
About auxiliary feeding system:
The PP strapping equipment is equipped with ---- 3 sets of auxiliary feeders,
Can add dyeing masterbatch------- change the color of PP strap
Can add filling masterbatch----- reduce the cost of PP strap by more than 30%
Can add defoaming agent-------- eliminate the moisture of PP raw materials
Services :
Technical Support and Service for pp strapping band making machine
We offer a wide range of technical support and services for our pp strapping band making machine products, including:
- Installation and commissioning of the extrusion line.
- Operational and maintenance training.
- Consultation and advice.
- Technical support.
- Spare parts supply.
- Regular maintenance.
- On-site repair and maintenance.
Packing and Shipping of pp strapping band making machine:
Packaging and Shipping for pp strapping band making machine:
- Product will be packaged in standard export cartons.
- The weight of each carton is less than 20KG.
- Transport methods include air, sea, express and railway.
